5000 series
LCD TV
47" Full HD 1080p digital TV
47PFL5609D/30
|
|
| Vivid and razor sharp pictures | |
|
Pixel Plus HD for better details, depth and clarityPixel Plus HD is a picture processing technology that enables viewers to watch content that is vivid, natural and real. The result are superbly life-like pictures with incredible details and depth from any HD source. |
|
Full HD LCD display, with a 1920x1080p resolutionThe Full HD screen has the widescreen resolution of 1920 x 1080p. This is the highest resolution of HD sources for the best possible picture quality. It is fully future proof as it supports 1080p signals from all sources, including the most recent like Blu-ray and advanced HD game consoles. The signal processing is extensively upgraded to support this much higher signal quality and resolution. It produces brilliant flicker-free progressive scan pictures with superb brightness and colors. |
|
Dynamic contrast 50000:1 for incredible rich black detailsYou want the LCD flat display with the highest contrast and most vibrant images. Philips advanced video processing combined with unique extreme dimming and backlight boosting technology results in vibrant images. Dynamic Contrast will increase the contrast with excellent blacklevel and accurate rendition of dark shades and colors. It gives a bright, lifelike picture with high contrast and vibrant colors. |
|
Native cinema mode for real movie experienceMovies and many prime time TV programs are captured at 24 frames per second (24p). Without changing the frames processing of the film, the TV displays movie content exactly at 24 frames per second, hencing recreating the exact same motion effect film producers have intended. |
| Pure and lifelike sound | |
|
2.1 channel surround with subwoofer for deep bassThis 2.1 channel surround with integrated subwoofer is a complete sound system that utilises Philips incredible surround sound processing technology. It amplifies the bass frequencies from the subwoofer and at the same time optimzing mid and low frequencies. The result is a system that powerfully reproduces the full range of audio frequencies from deep bass to crystal clear high notes. |
|
20W for superior sound clarity |
|
Invisible speakers with incredible surroundAn invisible sound system that blends perfectly with the design of the cabinet. The Incredible Surround allows you to experience total surround with greater depth and width of sound. It gives a clear and spacious sound stage complementary to the rich viewing experience. |
| Easy to connect and enjoy | |
|
USB for fantastic multimedia playbackThe USB connector allows access to jpeg photos, mp3 music and video files of most USB-sticks (USB memory-class device). Plug the USB into the slot at the side of the TV and access the multimedia content using the easy on screen content browser. You can now view and share your videos, photos and music. |
|
3 HDMI inputs with Easylink for a full HD connectionEasyLink uses the HDMI CEC industry standard protocol to share functionality between connected devices and the TV. With Easylink only one remote control is needed to operate main functionalities on your TV and connected devices. HDMI makes an uncompressed digital RGB connection from the source to the screen for the ultimate picture quality. HDMI uses HDCP copy protection. With 2 HDMI inputs on the back and 1 HDMI on the side of the TV you can connect multiple HD sources, for instance an HD settop box, a Blu-ray player, and Game Console or Digital Camcorder. |
Smart Picture and Smart Sound to personalize your viewingPhilips preset modes for Smart Picture and Smart Sound provide you with direct access via a single key on the remote control. You can select optimized picture and sound settings for the various picture and sound modes. |
|
| Ready for digital | |
|
Integrated digital tuner for digital receptionThe integrated digital tuner lets you receive digital cable and terrestrial TV without an additional set top box. Enjoy quality TV clutter free. |
| Picture/Display | |
| Aspect ratio | Widescreen |
| Brightness | 500 cd/m² |
| Dynamic screen contrast | 50000:1 |
| Response time (typical) | 5 ms |
| Viewing angle | 178º (H) / 178º (V) |
| Diagonal screen size (inch) | 47 inch |
| Diagonal screen size (metric) | 119 cm |
| Display screen type | LCD Full HD W-UXGA Act. matrix |
| Panel resolution | 1920x1080p |
| Picture enhancement | Pixel Plus HD, 3/2 - 2/2 motion pull down, 3D Combfilter, Active Control + Light sensor, Color Enhancement, Contrast Plus, Digital Noise Reduction, Dynamic contrast, Luminance Transient Improver, Dynamic Noise Reduction, 1080p 24/25/30Hz processing, 1080p 50/60Hz processing, HD Natural Motion |
| Screen enhancement | Semi-glare |
| Supported Display Resolution | |
| Computer formats | 640 x 480, 60Hz, 720 x 400, 70Hz, 800 x 600, 60, 72, 75, 85Hz, 1024 x 768, 60, 70, 75, 85Hz, 1280 x 768, 60Hz, 1280 x 1024, 60Hz, 1360 x 768, 60Hz, 1600 x 1200, 60Hz, 1920 x 1080, 60Hz |
| Video formats | 480i, 60Hz, 480p, 60Hz, 576i, 50Hz, 576p, 50Hz, 720p, 50, 60Hz, 1080i, 50, 60Hz, 1080p, 24, 25, 30, 50, 60Hz |
| Sound | |
| Output power (RMS) | 20W |
| Sound Enhancement | Auto Volume Leveller, Incredible Surround, Smart Sound, Subwoofer, Treble and Bass Control |
| Sound System | Mono, Nicam Stereo, Stereo |
| Loudspeakers | |
| Built-in speakers | 2 |
| Convenience | |
| Child Protection | Child Lock+Parental Control |
| Clock | Sleep Timer, Wake Up Timer |
| Ease of Installation | Autostore, Fine Tuning, PLL Digital Tuning, Program Name, Sorting |
| Ease of Use | Auto Volume Leveller (AVL), Channel list, Settings assistant Wizard, Side Control, EasyLink, One-stop Home button, Favorite program selection |
| Electronic Program Guide | Now + Next EPG, 7 day Electronic Program Guide |
| On-Screen Display languages | English, Simplified Chinese, Traditional Chinese |
| Remote Control | TV |
| Remote control type | PF07A09B |
| Screen Format Adjustments | 4:3, Auto Format, Movie expand 14:9, Movie expand 16:9, Subtitle Zoom, Super Zoom, Widescreen, unscaled (1080p dot by dot) |
| Signal strength indication | Yes |
| Firmware upgradeable | Firmware upgradeable via USB |
| Multimedia | USB media browser |
| Multimedia Applications | |
| Multimedia connections | USB |
| Playback Formats | AAC LC, MP3, AC3, JPEG Still pictures, MPEG1, MPEG4, H.264/MPEG-4 AVC |
| Playback enhancement | Picture slideshow |
| Tuner/Reception/Transmission | |
| Aerial Input | 75 ohm coaxial (IEC75) |
| TV system | PAL I, PAL B/G, PAL D/K, SECAM B/G, SECAM D/K |
| Video Playback | NTSC, SECAM, PAL |
| Tuner bands | Hyperband, S-Channel, UHF, VHF |
| Number of Preset Channels | 99 |
| Connectivity | |
| AV 1 | Audio L/R in, YPbPr |
| AV 2 | Audio L/R in, CVBS in |
| Front / Side connections | HDMI v1.3, S-video in, CVBS in, Audio L/R in, Headphone out, USB |
| Other connections | Monitor out, CVBS, L/R (cinch), PC-in VGA + Audio L/R in, S/PDIF out (coaxial) |
| HDMI 1 | HDMI v1.3 |
| HDMI 2 | HDMI v1.3 |
| EasyLink (HDMI-CEC) | One touch play, EasyLink, Remote control pass-through, System audio control, System standby |
| Power | |
| Ambient temperature | 5 °C to 35 °C |
| Mains power | 220-240V, 50/60Hz |
| Power consumption | 280 W |
| Standby power consumption | <0.15 |
| Dimensions | |
| Set Width | 1150 mm |
| Set Height | 712 mm |
| Set Depth | 88 mm |
| Set width (with stand) | 1150 mm |
| Set height (with stand) | 762 mm |
| Set depth (with stand) | 295 mm |
| Weight incl. Packaging | 32 kg |
| Product weight | 21 kg |
| Product weight (+stand) | 25 kg |
| Box width | 1463 mm |
| Box height | 871 mm |
| Box depth | 310 mm |
| VESA wall mount compatible | 400 x 400 mm |
| Accessories | |
| Included Accessories | Tabletop swivel stand, Power cord, Quick start guide, User Manual, Warranty certificate, Remote Control, Batteries for remote control |
| User Manual | English |
| Connector drawing |
|
